Marzocchi GHP1 Oil Gear Pump
|
TYPE |
Displacement |
FLOW at 1500r/min |
MAX PRESSURE |
MAX SPEED |
||
|
P1 |
P2 |
P3 |
||||
|
|
cm³/rev |
litri/min |
bar |
bar |
bar |
rpm |
|
GHP1-D(S)-3 |
2.1 |
2.9 |
270 |
290 |
310 |
6000 |
|
GHP1-D(S)-4 |
2.8 |
3.9 |
270 |
290 |
310 |
5000 |
|
GHP1-D(S)-5 |
3.5 |
4.9 |
270 |
290 |
310 |
5000 |
|
GHP1-D(S)-6 |
4.1 |
5.9 |
270 |
290 |
310 |
4000 |
|
GHP1-D(S)-7 |
5.2 |
7.4 |
260 |
275 |
290 |
3500 |
|
GHP1-D(S)-9 |
6.2 |
8.8 |
260 |
275 |
290 |
3000 |
|
GHP1-D(S)-11 |
7.6 |
10.8 |
230 |
245 |
260 |
3500 |
|
GHP1-D(S)-13 |
9.3 |
13.3 |
210 |
225 |
240 |
3000 |
|
GHP1-D(S)-16 |
11 |
15.7 |
200 |
215 |
230 |
2500 |
|
GHP1-D(S)-20 |
13.8 |
19.7 |
180 |
195 |
210 |
2000 |
Marzocchi GHP1 Oil Gear Pump
- Displacement: The marzocchi GHP1 oil gear pump series includes pumps with different displacements, typically ranging from 4.5 cc/rev to 13.9 cc/rev. This displacement determines the volume of hydraulic fluid the pump can deliver per revolution.
- Maximum Pressure: These pumps are designed to handle hydraulic systems with maximum pressures of up to 280 bar (4,060 psi).
- Speed Range: GHP1 pumps are typically used in hydraulic systems with speeds ranging from 800 to 3,000 RPM (revolutions per minute).
- Mounting Type: These pumps are available in various mounting configurations, including flange and European standard flange options.
High strength aluminum alloy material is applied, with light weight and easy installation
Axial clearance automatic compensation mechanism, radial hydraulic balance, maintaining high volumetric efficiency of the oil pump
CBW Hydraulic Gear Pump adopts self-lubricating bearings to improve the pump's load-bearing capacity
The connection forms of the inlet and outlet ports include threads, flanges, etc. for selection
The input shaft connection form can be selected from flat keys, rectangular splines, flat keys, semicircle keys, involute splines, SAE splines can be customized
Poocca Hydraulics (Shenzhen) Co., Ltd. was established in 1997. It is a comprehensive hydraulic service enterprise integrating R&D, manufacturing, maintenance and sales of hydraulic pumps, motors, valves and accessories. Extensive experience in providing power transmission and drive solutions to hydraulic system users worldwide.
After decades of continuous development and innovation in the hydraulic industry, Poocca Hydraulics is favored by manufacturers in many regions at home and abroad, and has also established a solid corporate partnership.
As a hydraulics manufacturer, we can provide you with custom solutions to meet your unique needs. To ensure your brand is represented accurately and effectively communicate the value of your hydraulic products to your target audience.
In addition to providing regular products, poocca also accepts special model product customization, which can be customized for your required size, packaging type, nameplate and logo on the pump body
POOCCA has many certificates and honors:
Certificates: patent certificates for plunger pumps, gear pumps, motors, and reducers. CE,FCC,ROHS.
Honors: counterpart support caring enterprises, honest enterprises, recommended procurement units for China-Africa economic and trade cooperation.
Q: Are you trading company or manufacturer?
A: We are manufacturer.
Q: How long is the Warranty?
A: One-year warranty.
Q: What is your payment terms?
A: 100% in advance, long-term dealer 30% in advance, 70% before shipping.
Q: How about the delivery time?
A: Conventional products take 5-8 days, and unconventional products depend on the model and quantity
| GHP1 TYPE | GHP2 TYPE | GHP3 TYPE |
| GHP1-D-2 | GHP2-D-6 | GHP3-D-30 |
| GHP1-D-3 | GHP2-D-9 | GHP3-D-33 |
| GHP1-D-4 | GHP2-D-10 | GHP3-D-40 |
| GHP1-D-5 | GHP2-D-12 | GHP3-D-50 |
| GHP1-D-6 | GHP2-D-13 | GHP3-D-60 |
| GHP1-D-7 | GHP2-D-16 | GHP3-D-66 |
| GHP1-D-9 | GHP2-D-20 | GHP3-D-80 |
| GHP1-D-11 | GHP2-D-22 | GHP3-D-94 |
| GHP1-D-13 | GHP2-D-25 | GHP3-D-110 |
| GHP1-D-16 | GHP2-D-30 | GHP3-D-120 |
| GHP1-D-20 | GHP2-D-34 | GHP3-D-135 |
| GHP1A-D-2 | GHP2-D-37 | GHP3-D-30 |
| GHP1A-D-3 | GHP2-D-40 | GHP3-D-33 |
| GHP1A-D-4 | GHP2-D-50 | GHP3-D-40 |
| GHP1A-D-5 | GHP2A-D-6 | GHP3-D-50 |
| GHP1A-D-6 | GHP2A-D-9 | GHP3-D-60 |
| GHP1A-D-7 | GHP2A-D-10 | GHP3-D-66 |
| GHP1A-D-9 | GHP2A-D-12 | GHP3-D-80 |
| GHP1A-D-11 | GHP2A-D-13 | GHP3-D-94 |
| GHP1A-D-13 | GHP2A-D-16 | GHP3-D-110 |
| GHP1A-D-16 | GHP2A-D-20 | GHP3-D-120 |
| GHP1A-D-20 | GHP2A-D-22 | GHP3-D-135 |
| GHP2A-D-25 | ||
| GHP2A-D-30 | ||
| GHP2A-D-34 | ||
| GHP2A-D-37 | ||
| GHP2A-D-40 | ||
| GHP2A-D-50 |
