A4VSO 40 HS410R PZB25N00-S2618 Piston Pump

Short Description:

Displacement Capacity: 40 cubic centimeters per revolution (40 cc/rev).
Maximum Pressure Rating: Can handle pressures of up to 350 bar.
Peak Operational Speed: Designed for speeds up to 3600 revolutions per minute (rpm).
Inlet Port Size: Features a G1/2 inlet port for fluid intake.
Outlet Port Size: Equipped with a G3/8 outlet port for fluid discharge.
Weight: The pump weighs approximately 21 kilograms.
Fluid Compatibility: Compatible with hydraulic oils and mineral-based fluids, ensuring versatile use in hydraulic systems.

Send email to us

Product Detail

Customer Feedback

Product Tags

Rexroth A4VSO Parameter

Size		NG		A4VSO 40
Geometric displacement		Vg max	cm3	40
per revolution		Vg max	cm3	40
Rotational speed	at Vg max 2)	nnom	rpm	2600
maximum1)	at Vg ≤ Vg max 3)	nmax	rpm	3200
Flow	at nnom and Vg max	qv	l/min	104
Flow	at 1500 rpm	qv	l/min	60
Power	at nnom, Vg max	P	kW	61
	and Δp = 350 bar	P	kW	61
	at 1500 rpm	P	kW	35
Torque	at nnom, Vg max	M max	Nm	223
	and Δp = 350 bar 2)	M max	Nm	223
	and Δp = 100 bar 2)	M	Nm	64
Rotary stiffness of drive shaft	Shaft end P	c	kNm/rad	80
Rotary stiffness of drive shaft	Shaft end Z	c	kNm/rad	77
Moment of inertia		JTW	kgm2	0.0049
Maximum angular acceleration4)		a	rad/s²	17000
Case volume		v	l	2
Weight (without through drive) approx.		m	kg	39
