T6DR T6DRY Industrial Hydraulic Vane Pumps
Compact Design, High Performance
The T6DR vane pump offers a compact design and pressures up to 275 bar, significantly saving installation space and associated costs. Its wide speed range and large-displacement pump element make it suitable for a wide range of industrial applications requiring flexibility and efficiency.
High Efficiency and Quiet Operation
The T6DR vane pump boasts a typical mechanical efficiency of up to 94%, minimizing heat generation and improving overall system performance. Its low-pulsation pressure design helps reduce pipe noise and protect other hydraulic components, resulting in quieter operation and extended system life.
Enhanced Durability and Installation Flexibility
The T6DR vane pump features a double-lip vane design, which provides strong resistance to particle contamination, ensuring extended pump life and reliable performance. A wide range of customizable options, including cam displacement, shaft type, and port configuration, allows for easy integration into a variety of hydraulic systems.
| 024-44611-0 | T6DR-020-1R00-B30-A1 | 024-31845-0/002 | T6DR-028-3L00-B22-A1 | 024-31456-0 | T6DR-035-1R00-A10-A1 | 024-33328-0 | T6DR-038-1R00-B20-A1 | 024-49275-0 | T6DR-042-2L00-C40-A1 |
| 024-33846-0 | T6DR-020-3L00-C42-A1 | 024-31845-0/020 | T6DR-028-3L02-B20-A1 | 024-40965-0 | T6DR-035-1R00-A20-A1 | 024-31854-0 | T6DR-038-1R00-B30-A1 | 024-31461-0/002 | T6DR-042-2R00-C42-A1 |
| 024-49454-0 | T6DR-024-1L00-B20-A1 | 024-31847-0 | T6DR-028-3R00-B20-A1 | 024-31849-0 | T6DR-035-1R00-B20-A1 | 024-45126-0 | T6DR-038-1R00-C40-A1 | 024-31461-0/012 | T6DR-042-2R01-C42-A1 |
| 024-45954-0 | T6DR-024-1R00-B20-A1 | 024-31847-0/010 | T6DR-028-3R01-B20-A1 | 024-31849-0/001 | T6DR-035-1R00-B21-A1 | 024-31139-0/002 | T6DR-038-1R00-C42-A1 | 024-31461-0/032 | T6DR-042-2R03-C42-A1 |
| 024-40946-0 | T6DR-024-1R00-C40-A1 | 024-31847-5/010 | T6DR-028-3R01-B20-A5 | 024-31849-0/002 | T6DR-035-1R00-B22-A1 | 024-31139-0/022 | T6DR-038-1R02-C42-A1 | 024-33239-0 | T6DR-042-3L00-B20-A1 |
| 024-44610-0 | T6DR-024-3L00-B30-A1 | 024-31847-0/012 | T6DR-028-3R01-B22-A1 | 024-49976-0 | T6DR-035-1R00-B30-A1 | 024-45126-0/030 | T6DR-038-1R03-C40-A1 | 024-33239-0/030 | T6DR-042-3L03-B20-A1 |
| 024-49235-0/020 | T6DR-024-3L02-B20-A1 | 024-49199-0/020 | T6DR-028-3R02-B30-A1 | 024-49976-0/001 | T6DR-035-1R00-B31-A1 | 024-31139-0/032 | T6DR-038-1R03-C42-A1 | 024-31460-0 | T6DR-042-3R00-B20-A1 |
| 024-31697-0 | T6DR-024-3R00-B20-A1 | 024-49199-0/021 | T6DR-028-3R02-B31-A1 | 024-40674-0/002 | T6DR-035-1R00-C42-A1 | 024-33237-0/002 | T6DR-038-2R00-C42-A1 | 024-49251-0/021 | T6DR-042-3R02-B31-A1 |
| 024-33847-0 | T6DR-024-3R00-B30-A1 | 024-31520-0 | T6DR-031-1L00-B20-A1 | 024-50640-0 | T6DR-035-2R00-A10-A1 | 024-33237-0/032 | T6DR-038-2R03-C42-A1 | 024-50718-0 | T6DR-045-1L00-C43-A1 |
| 024-31697-0/02 | T6DR-024-3R02-B20-A1 | 024-40890-0 | T6DR-031-1L00-B30-A1 | 024-40413-0 | T6DR-035-2R00-C42-A1 | 024-33626-0 | T6DR-038-3L00-B20-A1 | 024-31855-0 | T6DR-045-1R00-B20-A1 |
| 024-50178-0 | T6DR-028-1L00-B20-A1 | 024-40599-0 | T6DR-031-1R00-A10-A1 | 024-31850-0 | T6DR-035-3L00-B20-A1 | 024-49726-0 | T6DR-038-3R00-A20-A1 | 024-31138-0 | T6DR-045-1R00-C40-A1 |
| 024-31844-0 | T6DR-028-1R00-B20-A1 | 024-40599-0/001 | T6DR-031-1R00-A11-A1 | 024-31853-0 | T6DR-035-3L00-B30-A1 | 024-26834-0 | T6DR-038-3R00-B30-A1 | 024-31138-0/002 | T6DR-045-1R00-C42-A1 |
| 024-31844-0/002 | T6DR-028-1R00-B22-A1 | 024-31192-0 | T6DR-031-1R00-B20-A1 | 024-31453-0 | T6DR-035-3L00-C40-A1 | 024-31709-0 | T6DR-038-3R00-C42-A1 | 024-31855-0/03 | T6DR-045-1R03-B20-A1 |
| 024-40037-0 | T6DR-028-1R00-B30-A1 | 024-31458-0/002 | T6DR-031-1R00-C42-A1 | 024-31851-0 | T6DR-035-3R00-B20-A1 | 024-49726-0/011 | T6DR-038-3R01-A21-A1 | 024-31452-0 | T6DR-045-3L00-B20-A1 |
| 024-31289-0/002 | T6DR-028-1R00-C42-A1 | 024-31192-0/03 | T6DR-031-1R03-B20-A1 | 024-31851-0/002 | T6DR-035-3R00-B22-A1 | 024-31193-0/030 | T6DR-038-3R03-B20-A1 | 024-31044-0 | T6DR-045-3L00-C42-A1 |
| 024-31844-0/021 | T6DR-028-1R02-B21-A1 | 024-45338-0/010 | T6DR-031-2R01-C40-A1 | 024-31852-0 | T6DR-035-3R00-B30-A1 | 024-33240-0 | T6DR-042-1R00-A10-A1 | 024-31452-0/020 | T6DR-045-3L02-B20-A1 |
| 024-31844-0/022 | T6DR-028-1R02-B22-A1 | 024-31848-0 | T6DR-031-3L00-B20-A1 | 024-31852-0/002 | T6DR-035-3R00-B32-A1 | 024-31457-0 | T6DR-042-1R00-B20-A1 | 024-31452-0/030 | T6DR-045-3L03-B20-A1 |
| 024-33848-0 | T6DR-028-2L00-B20-A1 | 024-31848-4 | T6DR-031-3L00-B20-A4 | 024-31556-0 | T6DR-035-3R00-C42-A1 | 024-40111-0/002 | T6DR-042-1R00-C42-A1 | 024-26825-0 | T6DR-045-3R00-B20-A1 |
| 024-31846-0 | T6DR-028-3L00-A10-A1 | 024-33574-0 | T6DR-031-3R00-A20-A1 | 024-31556-0/023 | T6DR-035-3R02-C43-A1 | 024-40111-0/023 | T6DR-042-1R02-C43-A1 | 024-44965-0/002 | T6DR-045-3R00-C42-A1 |
| 024-31845-0 | T6DR-028-3L00-B20-A1 | 024-33423-0/002 | T6DR-031-3R00-C42-A1 | 024-31451-0/030 | T6DR-038-1L03-B20-A1 | 024-31457-0/030 | T6DR-042-1R03-B20-A1 | 024-50540-0 | T6DR-050-3R00-C40-A1 |
| T6DRY-045-1R00-C40-A1 | T6DRY-017-3L00-B40-A1 | 024-50540-0/003 | T6DR-050-3R00-C43-A1 | 024-50540-0/002 | T6DR-050-3R00-C42-A1 |
1: Selected raw materials
Strictly select raw materials, the front cover, pump body, back cover, and internal parts and components are all screened, tested, and strictly required for assembly testing and quality control
2: stable performance
Each structure is actuarial design, the internal structure is tightly connected, and the operation is stable, making it more durable, wear-resistant, impact-resistant, and lower noise
3: Strong corrosion resistance
In the production process, a variety of processes are used, which has good corrosion resistance, bright color and good metal texture.
As a hydraulics manufacturer, we can provide you with custom solutions to meet your unique needs. To ensure your brand is represented accurately and effectively communicate the value of your hydraulic products to your target audience.
In addition to providing regular products, poocca also accepts special model product customization, which can be customized for your required size, packaging type, nameplate and logo on the pump body
The Danfoss H1B motor’s zero-degree capability and maximum angle of 32 degrees meet a variety of applications:
Wheel assists on steering axes of high-inertia machines
Suitable for anti-skid control of off-highway machinery such as agricultural sprayers
Optimize working and transport modes in multi-motor applications such as wheel loaders
Improved gradeability of machines such as single-wheel rollers through precise anti-skid control.
SAE, cartridge and DIN flange options available with radial or axial high pressure port configurations, as well as loop flushing.
Pre-Sales Service: Prompt, professional response to inquiries, detailed product information and assistance in selecting the most appropriate hydraulic solution for a specific application. You'll be given guidance on product compatibility, performance optimization, and cost-effectiveness to ensure you make informed buying decisions.
After sales support:They provide timely and efficient assistance in case of product issues, troubleshooting or warranty claims. Our poocca customer service team will be approachable and responsive, addressing concerns and resolving issues promptly.
Delivery time: poocca has an efficient logistics and supply chain management system to ensure timely dispatch and delivery of products. We will provide accurate lead time estimates, proactively communicate any potential delays, and take necessary steps to minimize disruption. Additionally, we can offer expedited shipping options for rush orders, enabling you to receive your product within the requested time period.
As a competent manufacturer of diversified Hydraulic Pumps, we are thriving across the globe and we are happy to share the overwhelming positive feedback we have received from satisfied customers across the globe. Our products have won accolades for their superior quality and performance. Consistent positive reviews reflect the trust and satisfaction customers experience after making a purchase.
Join our customers and experience the excellence that sets us apart. Your trust is our motivation and we look forward to exceeding your expectations with our POOCCA hydraulic pump solutions.
